Rako Wireless Lighting RCS07-SS - 7 Button Keypad Brushed Stainless Steel - Hidden Screw Fixing

	Rako Wireless Lighting RCS07-SS - 7 Button Keypad Features
	Do not use on new projects Sold as replacement only Rako Wireless Lighting Control RCS07-SS - 7 Button Keypad - Brushed Stainless Steel - Hidden Screw Fixing. 4 preset scene selection and off plus master raise lower
	Wireless unit using lithium batteries - locate this any where in the room
	Use as part of a Mood Lighting scene setting configuration
	Simple to retro-fit to existing conventionally wired schemes
	Smooth cross fading between scenes
	Simple system configuration can be performed by non technical staff
	Flush mounting only to BS Standard back boxes
	Long battery life (in excess of 3 years), easily replaced by the user

	Advance Features
	The factory default 7 button keypad configuration is set for; 4 lightscens, off and raise lower. It is possible to programme these advance functions directly from the keypad.
	Channel Mode - The default keypad mode is to select 4 lightscens, off and raise lower. It is possible to set the keypad to channel mode, that is to toggle on/off 4 individual light circuits , all off and raise lower for each circuit.
	Power up mode - the default power up mode (after a power cut) is to set all lights on 100%. It is possible to select the following different power up modes - Lightscenes 1,2,3 or 4, all lights off, or last scene set
	Whole House All Off - It is possible to set the off button on any 7 button keypad to act as a whole house all off control. Once enabled, just by holding the off button for 4 seconds, turns all the lights out in the house
	Adjust Fade Rate - The default fade rate from Off to On is 2 seconds. It is possible to select a fade rate of 1, 4, or 10 seconds.

	Technical
Voltage	6V (2 x 3V Lithium coin cells CR2016 )
Back Box Type	BS Standard back box
Size (H, W, D) mm	88 x 88 x 7
Communication	RAKOM Coded FM Radio - 433.9MHz
Address	256 house and 256 room addresses
Channels	Up to 60 per room using RASOFT Pro Software for configuration
Channels	Up to 15 per room using this controller for configuration
Range	Transmitting range of 15m in building (100m line of sight)
Order Code	Rako Wireless Lighting Keypad - RCS07-SS
